Industry standard or
bespoke manufactured

External Oval Glove Port
200 x 400mm

Designed in a similar way to our small external port, MIP Ltd’s 200 x 400mm External Oval Glove Port offers a highly practical and secure solution for glovebox and containment applications where additional manoeuvrability and reach are essential.

Manufactured in the UK, the assembly consists of a port, inner securing ring and two gaskets, creating a robust fixing arrangement suitable for a wide range of controlled environments.

Standard Port Assembly

Each 200 x 400 External Oval Glove Port assembly comprises:

• Acetal external oval glove port
• Acrylic pressure ring
• 2 x Neoprene Gasket
• Stainless steel fixing screws

The assembly is secured using pan head threaded screws, which clamp the port, gaskets, and securing oval firmly into position, providing a reliable seal and secure installation.

Unique External-Mount Design
The distinctive design of the external oval port allows the port to be installed on a screen of any thickness and enable the user to reach right into the glovebox or containment application.

Secure Glove Retention
The glove port features two integrated retaining grooves, allowing the beaded cuff of a glove to locate securely within the port. This design helps maintain glove positioning and provides a dependable connection between the glove and the enclosure.

Installation Information
The standard 200 x 400 external oval assembly is designed for installation onto screens or windows of any thickness.
